Air Release and Vacuum Issues

Air is present in all water and waste water pipelines. The air may be absorbed at free surface or entrained in turbulent flow at the entrance to the line, changes in direction or incline. The air may therefore be in the water or in the form of bubbles or pockets.

Air pockets
An air pocket implies a relatively large volume of air, likely to accumulate on top of the pipe cross section. The pockets may travel along the line to peaks. Where they will either remain in equilibrium, be entrained by the flowing water or be released through air valves.

Air valves are globally recognised as the most effective airflow control valve associated with fluid dynamics. Their contribution to efficient flow of fluids engage with energy savings, extension of the pipeline asset life and management of surge characteristics that can damage new and older pipelines.

Some of the issues and essentially dangers attributed to the presence of air within pressurised pipe systems can be categorised as follows:

Reduction of effective bore of pipeline, causing in extreme cases complete blockages.

• Measurable energy losses.
• Water hammer or localised surges.
• Meters being affected and misreading flows in conjunction with premature failure due to internal damage to meters.
• Localised reduction in water supply or pressure
• Extensive corrosion of pipeline resulting in premature failure.
• Excessive localised pressures that could cause a danger to operators during maintenance or operation.

Eliminating the air in pipelines

Kinetic or large orifice, used to release large quantities of air during the filling of the line and to draw air in from the atmosphere during vacuum conditions in the line.

Automatic or small orifice, the part of the valve that will continue to operate when the pipeline is under full pressure and releases small volumes of high pressure air and double orifice or combination air valve, which combines kinetic and automatic into one valve.

Recommended locations of the air valves would be catagorised as follows;

• Pump stations: after the pump and after the check valve.
• After and before shut-off valve.
• After deep-well pump.
• On long hydraulic gradient water supply lines.
• At peaks relative to hydraulic gradient.
• At the end of lines.
• Before water meter.

Air bubbles
The air bubbles themselves often form in the following locations or are caused by conditions within the system:

• At a throttle or orifice.
• Where there is a pressure drop.
• At a branch or pipe joint.
• From a valve opening and closing rapidly.
• From shock waves, due to sudden closing of valves or cessation of pump operation.
• Pressure drop at the pipe end, due to sudden opening of valve.
